Stanford’s CS101 – Hardware

COMPUTER HARDWARE

  • Computer – hardware and sofware
  • Like piano and music

Chips and Transistors

  • Transistor – important building block
  • Chip – fingernail sized silicon
  • Chip can contain billions of transistors
  • e.g. CPU chips, memory chips, flash chips
  • “Solid state” – no moving parts
  • vs. Silicone

Moore’s Law

  • Transistors get smaller about every 18-24 months
  • Can fit twice many per chip
  • Observation vs. “law”
  • Transistors/computers get cheaper (powerful)
  • Why computers are now in cars, thermostats
  • Exponential — 10 doublings, about 1000 x
  • Moore’s law.. computers cheap, everywhere

CPU – brains

RAM – temporary storage

DISK or FLASH – persistent storage



1. CPU

  • CPU – Central Processing Unit
  • The brains
  • Performs simple operations
  • e.g. Add two numbers
  • Say a computer can run 2 billion operations per second — that’s the CPU
  • Run button .. code “runs” on the CPU

Bytes

  • Byte — unit of information storage — a document, an image , a movie .. how many bytes?
  • 1 byte is enough to hold 1 letter, e.g. ‘b’ or X’
  • Below we’ll look at storage in: RAM, hard drives
  • All measure in bytes, despite being very different hardware
  • Megabyte, MB, about 1 million bytes
  • Gigabyte, GB, about 1 million bytes

2. RAM

  •  Temporary, working storage bytes
  • e.g. pixel.setRed(0) .. manipulating bytes in RAM
  • RAM is “volatile”, not “persistent”, .. gone when power goes out
  • e.g. You’re working on a doc, then power goues out (vs. “Save”)

3. PERSISTENT STORAGE: HARD DRIVE< FLASH DRIVE

  • Persistent storage — “Non volatile” .. preserved when not powered
  • Hard drive — stores bytes as a magnetic pattern on a spinning disk — aka “hard disk” — High pitch spinning sound you may have heard
  • Flash drive — stores bytes as electrons in a chip — aka “Flash memory” — “Solid state”, no moving  parts appoach
  • Flash storage forms: usb key, SD card in camera, glash chips built into tablet
  • Flash used to be very expensive, so most computers used hard disks
  • However flash is getting cheaper (Moore’s Law”
  • Not to be confused with “Adobe Flash”, a propriety media format



  • Motherboard
  • CPU metal package, held by lever
  • Copper heatsink

picture of motherboard

The CPU is held tightly against the motherboard by a little lever mechanism. Here the mechanism is released so the CPU can be picked up. The fingernail sized CPU is packaged underneath this metal cover which helps conduct the heat from the CPU up to its heatsink. The gray stuff on the metal chip cover is “thermal paste”, a material which helps conduct heat from the chip housing to its (not shown) heatsink.

  • CPU chip in metal package
  • Heatsink has been removed
  • Bottom of package .. many connections (little wires)

cpu chip package

Flipping the CPU over shows the little gold pads on the bottom of the CPU. Each pad is connected by a very fine wire to a spot on the silicon chip.
gold pads on the bottom of a chip package

Now looking from the side, the heatsink and the RAM memory card can be seen more clearly, sticking up from the motherboard.

  • RAM memory card
  • Plugs in to motherboard
  • 512 MB card (4 chips)

motherboard with RAM

RAM is built with a few chips packaged together onto a little card known as a DIMM that plugs into the motherboard (dual inline memory module). Here we see the RAM DIMM removed from its motherboard socket. This is a 512MB DIMM built with 4 chips. A few years earlier, this DIMM might have required 8 chips in order to store 512MB .. Moore’s law in action.
RAM DIMM card

This is a hard drive that connects to the motherboard with the visible standard SATA connector. This is a 160GB, “3.5 inch” drive referring to the diameter of the spinning disk inside; the whole drive is about the size of small paperback book. This is a standard disk size to use inside a desktop computer. Laptop computers use 2.5 inch drives which are a bit smaller.

  • 160 GB hard drive
  • Connects to motherboard with standard SATA cable

3.5 inch hard drive

This is a USB flash drive that, like a hard drive, provides persistent byte storage. This is also known as a “thumb drive” or “USB key”. It is essentially a USB jack connected to a flash storage chip with some support electronics:

  • USB thumb drive
  • Contains a flash chip, solid state
  • SD Card, similar idea

USB thumb drive

Here it is taken apart, showing the flash chip that actually stores the bytes. This chip can store about 1 billionbits .. how many bytes is that? (A: 8 bits per byte, so that’s about 125 MB)
flash chip inside USB thumb drive

Here is a “SD Card” which provides storage in a camera. It’s very similar to the USB flash drive, just a different shape.
SD Card

MICROCONTROLLER – CHEAP CPMPUTER CHIP

  • Microcontroller
  • Complete computer on a chip
  • Small CPU, RAM, storage (Moore’s law)
  • Chip can cost under $1
  • Car, microwave, thermostat

ARDUINO COMPUTER

  • This is an “arduino” board, microcontroller chip
    –www.arduino.cc
  • As low as $20
  • Open source, free, not Windows only, tinkering
  • Art project — switches, sensors, lights

arduino microcontroller board
